splicing Eloik ALK-88A Fiber Optic Fusion Splicer fiber splicer machine

Ask Lasest Price
Brand Name :	Eloik
Model Number :	ALK-88A
Price :	920$/PIECE
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	1000piece per month
Delivery Time :	5-7days

Add to Cart

Product Details
Company Profile

splicing Eloik ALK-88A Fiber Optic Fusion Splicer fiber splicer machine

splicing Eloik ALK-88A Fiber Optic Fusion Splicer fiber splicer machine

Applicable Optical Fiber Types	SM(Single mode), MM(Multi-mode), DS(Dispersion shift), NZDS(Non zero dispersion shift)
Applicable Optical Fiber Core Number	Single core
Applicable Optical Fiber Diameter	Cladding diameter: 80-150μm, Coating diameter: 100～1000μm
Fusion splice Model	Prestore:40 groups, User define: 80 groups
Average using Splice Loss	0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS),0.04db(BIF/UBIF)
Echo Loss	Better than 60dB
Fusion splice Duration Time	9sec(typical parameter) /7 the sec (fast mode)
Loss Estimation of Fusion Splice	Exist
Tension Test	2N
Monitor	4.3 inches colorized LCD, Support in both Chinese and English, Spanish, Russian, French, Portuguese and other display
Power Supply	6800mAh Lithium battery, 13.5V/5A power adapter
Optical Fiber Magnification Times	X/Y:180times,X or Y:360 times
Battery	Typically work 220 times(Fusion splicing / Heating /Hot stripping), Single battery charge 2Hour,can be recycled 500 times
Splice Results Storage	10000 groups of the latest records
Data Interface	USB2.0
Operating Environment	Elevation:0~5000m, Relative humidity:0~95%,Temperature:-20°C~55°C,Maximum wind speed:15m/s
Storage Environment	Relative humidity:0~95%, Temperature:-40°C~80°C (Except Battery), Temperature:-10°C~40°C (Battery)
Weight of the Equipment	1.93kg(Include battery)
High altitude operation	Cornering, machines can be directly hung on the operators neck normal operation
Applicable Optical Fiber Cable Diameter	250μm, 900μm, 2~3mm
Applicable Sleeve Length	60mm, 45mm, 40mm(FP-03)
Heating time	20mm,40mm Fusion-Protection Sleeves only need 7-10s 60mm Fusion-Protection Sleeves 17s (customizable)
Heating temperature	180~250°C(customizable)
