Unit

Values

Operating Reach

m

10K

Transmit

Center wavelength (range)

nm

1260 -1355

Side Mode Suppression Ratio (min)

dB

30

Launched power

– maximum

dBm

+0.5

– minimum

dBm

-8.2 Notes1

- OMA

dBm

-5.2

- OMA-TDP (min)

dBm

-6.2

Transmitter and dispersion penalty

dB

0 Notes4

Average launch power of OFF transmitter (max)

dBm

-30

Extinction ratio (min)

dB

3.5 Notes2

RIN12 OMA (max)

dB/Hz

-128

Optical Return Loss Tolerance (min)

dB

12

Receiver

Center wavelength (range)

nm

1260-1355

Receive overload (max) in average power1

dBm

0.5

Receive sensitivity (min) in average power1

dBm

-14.4 Notes3

Receiver sensitivity (max) in OMA (footnote 2)

dBm

-12.6 Notes3

Receiver Reflectance (max)

dB

-12

Stressed receiver sensitivity (max) in OMA2

dBm

-10.3

Vertical eye closure penalty (min)3

dB

2.2

Stressed eye jitter (min)2

UIp-p

0.7

Receive electrical 3dB upper cutoff frequency (max)

GHz

12.3

Receiver power (damage, Max)

dBm

1.5
